型材规格

君华股份常规型号规格查询表:君华股份提供丰富多样的各类尺寸规格,满足不同客户的不同需求,同时支持尺寸定制。
同时,除了整米的型材型号,还提供零头型材库存查询>>

Image Description
序号 规格尺寸 (宽度*厚度(mm)) 尺寸公差 (mm)
1 600*5 +0.1/+1.0
2 600*6 +0.1/+1.0
3 600*7 +0.1/+1.0
4 600*8 +0.1/+1.5
5 600*10 +0.1/+1.5
6 600*12 +0.3/+1.5
7 600*15 +0.3/+1.5
8 600*16 +0.3/+1.5
9 600*18 +0.3/+1.5
10 600*20 +0.3/+1.5
11 600*22 +0.3/+1.5
12 600*25 +0.3/+1.5
13 600*28 +0.3/+2.0
14 600*30 +0.3/+2.0
15 600*32 +0.3/+2.0
16 600*35 +0.3/+2.0
17 600*40 +0.3/+2.0
18 600*45 +0.3/+2.0
19 600*50 +0.3/+2.5
20 600*55 +0.3/+2.5
21 600*60 +0.3/+3.0
22 600*65 +0.3/+3.0
23 600*70 +0.3/+3.5
24 600*75 +0.3/+3.5
25 600*80 +0.3/+4.0
26 600*85 +0.3/+4.0
27 600*90 +0.3/+4.0
28 600*95 +0.3/+4.0
29 600*100 +0.3/+5.0
30 1250*5 +0.1/+1.0
31 1250*6 +0.1/+1.0
32 1250*7 +0.1/+1.0
33 1250*8 +0.1/+1.5
34 1250*10 +0.1/+1.5
35 1250*12 +0.3/+1.5
36 1250*15 +0.3/+1.5
37 1250*16 +0.3/+1.5
38 1250*18 +0.3/+1.5
39 1250*20 +0.3/+1.5
40 1250*22 +0.3/+1.5
41 1250*25 +0.3/+1.5
42 1250*28 +0.3/+2.0
43 1250*30 +0.3/+2.0
44 1250*32 +0.3/+2.0
45 1250*35 +0.3/+2.0
46 1250*40 +0.3/+2.0
47 1250*45 +0.3/+2.0
48 1250*50 +0.3/+2.5
49 1250*55 +0.3/+2.5
50 1250*60 +0.3/+3.0
51 1250*65 +0.3/+3.0
52 1250*70 +0.3/+3.5
53 1250*75 +0.3/+3.5
54 1250*80 +0.3/+4.0
55 1250*85 +0.3/+4.0
56 1250*90 +0.3/+4.0
57 1250*95 +0.3/+4.0
58 1250*100 +0,3/+5.0
59 185*173 +0.3/+5.0
60 186*141 +0.3/+5.0
61 207*78 +0.3/+5.0
62 365*205 +0.3/+5.0
63 407*125 +0.3/+5.0
